Review of Helmsman 26

The hull is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season. And outside the sailing season, just bottom cleaning and perhaps anti-fouling painting once a year - a few hours of work, that's all.

The boat equipped with a fractional rig. A fractional rig has smaller headsails which make tacking easier, which is an advantage for cruisers and racers, of course. The downside is that having the wind from behind often requires a genaker or a spinnaker for optimal speed.

The keel is made of lead. Compared with iron, lead has the advantage of being 44% heavier, which allows a smaller keel and hence less water resistance and higher speed.

The boat can enter even shallow marinas as the draft is just about 1.45 - 1.55 meter (4.76 - 5.06 ft) dependent on the load. See immersion rate below.

What is Capsize Screening Formula (CSF)?

The capsize screening value for Helmsman 26 is 2.15, indicating that this boat would not be accepted to participate in ocean races.

The immersion rate is defined as the weight required to sink the boat a certain level. The immersion rate for Helmsman 26 is about 150 kg/cm, alternatively 840 lbs/inch.
Meaning: if you load 150 kg cargo on the boat then it will sink 1 cm. Alternatively, if you load 840 lbs cargo on the boat it will sink 1 inch.

What is L/B (Length Beam Ratio)?

The l/b ratio for Helmsman 26 is 2.86.

Compared with other similar sailboats it is more spacy than 73% of all other designs. It seems that the designer has chosen a slightly more spacy hull design.

What is a Ballast Ratio?

The ballast ratio for Helmsman 26 is 37%.

This ballast ratio shows a righting moment that is higher than 38% of all similar sailboat designs. A righting moment (ability to resist heeling) just below average.

What is SA/D (Sail Area Displacement ratio)?

The SA/D for Helmsman 26 with ISO 8666 reference sail is 16.0, with a 135% genua the SA/D is 19.2.

The SA/D ratio indicates that it is faster than 50% of all similar sailboat designs in light wind.

The Helmsman 26 has more rig than 85% of all similar sailboats, which indicates that the boat is significantly overrigged.

What is Relative Speed Performance?

The Relative Speed Performance for Helmsman 26 is 42

The relative speed performance is 42 which means that a it is faster than 42% of all similar sailboat designs.

Dimensions of sail for fractional rig.

Are your sails worn out? You might find your next sail here: Sails for Sale

If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.

This section shown boat owner's changes, improvements, etc. Here you might find inspiration for your boat.

Do you have changes/improvements you would like to share? Upload a photo and describe what to look for.

We are always looking for new photos. If you can contribute with photos for Helmsman 26 it would be a great help.

If you have any comments to the review, improvement suggestions, or the like, feel free to contact us. Criticism helps us to improve.

[Ref 1]: ISO 8666 Small craft — Principal data.
[Ref 3]: ISO 12215-5 Small craft — Hull construction and scantlings.
