Review of Pirate
Basic specs.
Looking for a new boat? Find a Pirate or similar boat for sale
The hull is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season. And outside the sailing season, just bottom cleaning and perhaps anti-fouling painting once a year - a few hours of work, that's all.
The boat is equipped with 3 berths and a galley.
The Pirate is built with a fractional rig. A fractional rig has smaller headsails which make tacking easier, which is an advantage for cruisers and racers, of course. The downside is that having the wind from behind often requires a gennaker or a spinnaker for optimal speed.
The Pirate has been built with different keel alternatives.
Unknown keel type
The boat can enter even shallow marinas as the draft is just about 0.69 - 0.79 meter (2.26 - 2.56 ft) dependent on the load. See immersion rate below.
CentreBoard
One option is a centreboard keel. A centreboard keel is a pivoting lifting keel, allowing to sail both coastal and inland waters.
Pirate can sail close to the beach as the draft is just 0.18 - 0.28 meter (0.59 - 0.89 ft) dependent of the load. See immersion rate below.
Fin keel
Another option is a fin keel. The fin keel is the most common keel and provides splendid manoeuvrability. The downside is that it has less directional stability than a long keel.
The boat can enter even shallow marinas as the draft is just about 1.14 - 1.24 meter (3.74 - 4.04 ft) dependent on the load. See immersion rate below.
An outboard motor is often used on this boat. In that case the boat will typically require a power of 1 - 2 hp, alternatively 25 - 30 lbs thrust if you prefer an electrical motor. Electric outboards are becoming popular for sailboat owners who want clean instant power with less noise and no exhaust fumes.
Sailing characteristics
This section covers widely used rules of thumb to describe the sailing characteristics. Please note that even though the calculations are correct, the interpretation of the results might not be valid for extreme boats.
What is Capsize Screening Formula (CSF)?
The capsize screening value for Pirate is 2.50, indicating that this boat would not be accepted to participate in ocean races.
The immersion rate is defined as the weight required to sink the boat a certain level.
The immersion rate for Pirate is about 72 kg/cm, alternatively 408 lbs/inch.
Meaning: if you load 72 kg cargo on the boat then it will sink 1 cm.
Alternatively, if you load 408 lbs cargo on the boat it will sink 1 inch.
Sailing statistics
This section is statistical comparison with similar boats of the same category. The basis of the following statistical computations is our unique database with more than 26,000 different boat types and 350,000 data points.
What is L/B (Length Beam Ratio)?
The l/b ratio for Pirate is 2.54.
The ballast ratio for Pirate is 42%.
SA/D (Sail Area Displacement ratio)
Indicates how fast the boat is in light wind:
- Cruising Boats have ratios 10-15
- Cruiser-Racers have ratios 16-20
- Racers have ratios above 20
- High-Performance Racers have ratios above 24
Sail-area/displacement ratio (SA/D ratio): 19.59
Maintenance
If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.
| Usage | Length | Diameter | ||
| Jib sheet | 5.3 m | (17.3 feet) | 8 mm | (5/16 inch) |
| Genoa sheet | 5.3 m | (17.3 feet) | 8 mm | (5/16 inch) |
| Mainsheet | 13.1 m | (43.1 feet) | 8 mm | (5/16 inch) |
| Spinnaker sheet | 11.6 m | (38.0 feet) | 8 mm | (5/16 inch) |
